SPECIFICATION
| Product No | HK300T03 |
|---|---|
| Nominal Input (Ipn) | 300 Arms |
| Max Input (Ip) | ± 600 A |
| Supply Voltage | ±12 ... ± 15 V |
| Output @Ipn | ± 4.0 V |
| Bandwidth -3dB | DC - 20 kHz |
| Accuracy | ± 2.0 % |
| Secondary Termination | Connector Header |
| Mounting Type | Panel |
KEY FEATURES
- DC, AC current measurements with galvanic isolation.
- Split core or clamp on current sensors
- Low power consumption
- Good accuracy at nominal current
RELATED APPLICATION
- DC energy meters.
- Telecom power supplies
- Battery energy management
